产品选择器
5 个结果
Loading
|
Part No
|
Supply Voltage (V) Min
|
Supply Voltage (V) Max
|
H Bridge Number
|
Power MOSFET
|
Drive Current (A)
|
Control Interface
|
Oscillator
|
Protection Features
|
PWM Frequency (kHz) Max
|
Microstepping
|
Temperature Junction Range (°C)
|
Package
|
MPQ（PCS）
|
MOQ（PCS）
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.5 | 10.8 | 2 | Internal | 1 | PWM | - | OCP/SCP/TSD/UVLO | 200 | NA | -40℃~85℃ | eTSSOP16 | 3000 | 3000 | |
| 2.5 | 10.8 | 2 | Internal | 0.9 | PWM | - | OCP/SCP/TSD/UVLO | 200 | NA | -40℃~85℃ | QFN16 | 3000 | 3000 | |
| 1.8 | 5.5 | 5 | Internal | 0.5 | IIC | extend | OCP/TSD/UVLO | - | Full/Half/32 Micro-Steps/64 Micro-Steps | -40℃~85℃ | QFN20 | 5000 | 5000 | |
| 3 | 5.5 | 5 | Internal | 0.5 | 4-Line Serial Data | extend | OCP/TSD/UVLO | - | 256-step | -40℃~85℃ | QFN44 | 3000 | 3000 | |
| 3 | 5.5 | 5 | Internal | 0.5 | 4-Line Serial Data | extend | OCP/TSD/UVLO | - | 256-step | -40℃~85℃ | QFN44 | 4000 | 3000 |
